Specification L

Technical data

Download Center Technical card

Metric units

Imperials units

PED

ASME

Type

Dimensions [mm]
A	B	C	D	E	F

Max. no. of plates

Weightkg

LA12

154

190

16/20

9 + 2,45*NP

0,4 + 0,049*NP

LA14

164

203

16/20

9 + 2,30*NP

0,6 + 0,049*NP

LA21AS

278

314

11 + 2,3*NP

0,58 + 0,06*NP

LA22

260

299

16/20

9 + 2,30*NP

0,8 + 0,073*NP

LA22(X)

260

299

16/20

9 + 1,9*NP

0,8 + 0,073*NP

LA34

432

471

16/20

9 + 2,30*NP

1,2 + 0,116*NP

LJ30

270

318

9 + 1,70*NP

1,1 + 0,064*NP

LH40

415

461

10 + 2,25*NP

1,7 + 0,134*NP

LB31

232

286

123

10 + 2,35*NP

150

1,6 + 0,114*NP

LB47

360

417

123

10 + 2,35*NP

150

2,1 + 0,168*NP

LB60

480

538

123

11 + 2,35*NP

150

2,6 + 0,219*NP

LB60(X)

480

538

123

11 + 1,95*NP

150

2,6 + 0,219*NP

LM110

520

620

191

10 + 2,60*NP

200

10,04 +0,408*NP

LM110(X)

520

620

192

10 + 2 × 2*NP

200

10,04 + 0,408*NP

LC110

170

378

466

258

28/38; 100

11 + 2,40*NP

200

10,64+0,408*NP

LC110AS

170

378

466

258

28/38; 100

11 + 2,40*NP

200

8,7 + 0,408*NP

LC170

170

600

688

258

28/38; 100

11 + 2,40*NP

200

13,44+0,617*NP

LD235

204

682

788

310

100

13 + 2,6*NP

280

40 + 0,828*NP

LE400

240

861

1 008

387

17 + 2,75*NP

400

74,3 + 1,625*NP

LF700

325

1100

1327

552

115

19 + 2,3*NP

400

159,2 + 3,35*NP

LA12

154

190

16/18

9+2,54*NP

0,4+0,05*NP

LA14

164

202

16/20

9+2,29*NP

0,6+0,05*NP

LA21AS

277

340

10+2,29*NP

0,6+0,059*NP

LA22

260

298

16/20

9+2,29*NP

0,8+0,073*NP

LA22(X)

260

298

16/20

9+1,78*NP

0,8+0,073*NP

LA34

432

471

16/20

9+2,29*NP

1,2+0,118*NP

LJ30

270

318

9+1,78*NP

1,1+0,064*NP

LH40

415

461

10+2,29*NP

1,7+0,136*NP

LB31

232

286

123

10+2,29*NP

150

1,6+0,113*NP

LB47

360

417

123

10+2,29*NP

150

2,1+0,168*NP

LB60

480

538

123

11+2,29*NP

150

2,6+0,218*NP

LB60(X)

480

538

122

11+2,03*NP

150

2,6+0,218*NP

LM110

520

619

190

10+2,54*NP

200

10+0,408*NP

LM110(X)

521

620

191

10+2,03*NP

200

10+0,408*NP

LC110

170

378

466

258

28/38

11+2,29*NP

200

10,64+0,408*NP

LC110AS

170

378

467

259

10+2,29*NP

200

8,7+0,408*NP

LC170

170

600

688

258

28/38

11+2,29*NP

200

13,44+0,617*NP

LD235

204

682

788

310

100

13+2,6*NP

280

40+0,83*NP

LE400

240

861

1008

387

17+2,79*NP

400

74,3+1,624*NP

LF700

325

1100

1327

552

140

17+2,29*NP

400

184,6+3,352*NP

Type

Dimensions [in]
A	B	C	D	E	F

Max. no. of plates

Weightlb

LA12

1,57

6,06

7,48

2,83

0,63/0,79

0,35+0,10*NP

0,88+0,11*NP

LA14

1,65

6,46

7,99

3,19

0,63/0,79

0,35+0,09*NP

1,32+0,11*NP

LA21AS

1,57

10,94

12,36

2,87

0,55

0,43+0,09*NP

1,28+0,13*NP

LA22

1,65

10,24

11,77

3,19

0,63/0,79

0,35+0,09*NP

1,76+0,16*NP

LA22(X)

1,65

10,24

11,77

3,19

0,63/0,79

0,35+0,07*NP

1,76+0,16*NP

LA34

1,65

17,01

18,54

3,19

0,63/0,79

0,35+0,09*NP

2,65+0,26*NP

LJ30

1,81

10,63

12,52

3,86

0,79

0,35+0,07*NP

2,43+0,14*NP

LH40

1,69

16,34

18,15

3,50

1,10

0,39+0,09*NP

3,75+0,3*NP

LB31

2,68

9,13

11,26

4,84

1,10

0,39+0,09*NP

150

3,53+0,25*NP

LB47

2,68

14,17

16,42

4,84

1,10

0,39+0,09*NP

150

4,63+0,37*NP

LB60

2,68

18,90

21,18

4,84

1,10

0,43+0,09*NP

150

5,73+0,48*NP

LB60(X)

2,68

18,90

21,18

4,84

1,10

0,43+0,08*NP

150

5,73+0,48*NP

LM110

3,58

20,47

24,41

7,52

1,89

0,39+0,1*NP

200

22,13+0,9*NP

LM110(X)

3,58

20,47

24,41

7,56

1,89

0,39+0,08*NP

200

22,13+0,9*NP

LC110

6,69

14,88

18,35

10,16

1,1/1,5; 3,94

0,43+0,09*NP

200

23,46+0,90*NP

LC110AS

6,69

14,88

18,35

10,16

1,1/1,5; 3,94

0,43+0,09*NP

200

19,18+0,9*NP

LC170

6,69

23,62

27,09

10,16

1,1/1,5; 3,94

0,43+0,09*NP

200

29,63+1,6*NP

LD235

8,03

26,85

31,02

12,20

3,94

0,51+0,1*NP

280

88,18+1,83*NP

LE400

9,45

33,90

39,68

15,24

3,66

0,67+0,11*NP

400

163,8+3,58*NP

LF700

12,80

43,31

52,24

21,73

4,53

0,75+0,09*NP

400

350,98+7,39*NP

LA12

1,6

6,1

7,5

2,8

0,63/0,79

0,35+0,10*NP

0,88+0,11*NP

LA14

1,7

6,5

8,0

3,2

0,63/0,79

0,35+0,09*NP

1,32+0,11*NP

LA21AS

1,6

10,9

13,4

2,9

0,6

0,39+0,09*NP

1,28+0,13*NP

LA22

1,7

10,2

11,8

3,2

0,63/0,79

0,35+0,09*NP

1,76+0,16*NP

LA22(X)

1,7

10,2

11,8

3,2

0,63/0,79

0,35+0,07*NP

1,76+0,16*NP

LA34

1,7

17,0

18,5

3,2

0,63/0,79

0,35+0,09*NP

2,65+0,26*NP

LJ30

1,8

10,6

12,5

3,9

0,79

0,35+0,07*NP

2,43+0,14*NP

LH40

1,7

16,3

18,1

3,5

1,1

0,39+0,09*NP

3,75+0,30*NP

LB31

2,7

9,1

11,3

4,8

1,1

0,39+0,09*NP

150

3,53+0,25*NP

LB47

2,7

14,2

16,4

4,8

1,1

0,39+0,09*NP

150

4,63+0,37*NP

LB60

2,7

18,9

21,2

4,8

1,1

0,43+0,09*NP

150

5,73+0,48*NP

LB60(X)

2,7

18,9

21,2

4,8

1,1

0,43+0,08*NP

150

5,73+0,48*NP

LM110

3,6

20,5

24,4

7,5

1,89

0,39+0,10*NP

200

22,13+0,90*NP

LM110(X)

3,6

20,5

24,4

7,5

1,9

0,39+0,08*NP

200

22,13+0,90*NP

LC110

6,7

14,9

18,4

10,2

1,1/1,5; 3,94

0,43+0,09*NP

200

23,46+0,90*NP

LC110AS

6,7

14,9

18,4

10,2

1,9

0,39+0,09*NP

200

19,18+0,90*NP

LC170

6,7

23,6

27,1

10,2

1,1/1,5; 3,94

0,43+0,09*NP

200

29,63+1,36*NP

LD235

8,0

26,9

31,0

12,2

3,94

0,51+0,10*NP

280

88,18+1,83*NP

LE400

9,5

33,9

39,7

15,2

3,66

0,67+0,11*NP

400

163,80+3,58*NP

LF700

12,8

43,3

52,2

21,7

5,51

0,75+0,09*NP

400

406,97+7,39*NP
